Audio Plug BS1363 Britain UK Power Plug Silver, Rhodium Plated

Share to:

Audio Plug BS1363 Britain UK Power Plug Silver, Rhodium Plated

Specifications

• Product NO : JT-BP-8SL-77

• Standard : UK BS1363 (British Standard)

• Rated Standard : AC 250V/13A

• Fire Rating : UL 94V-0~2

• All Screw Material : Stainless Steel 304 Rhodium Plated or Stainless Natural Color

• Terminal Material : Brass or Copper Plating Rhodium

• Maximum Diameter Of Cable: 20mm

• Get certified to UKCA

• High Quality Silver Painting Shell

Availability:

Quantity:



Inquire Add to Basket

Model:
JT-BP-8SL-77
Brand:
JAKE TIME or OEM

Audio Grade Power Plugs & Connectors Series

《Product Features》

．Three-layered plating process technology on terminal clamp, rivets, screws and grounding terminal

1. Plating: improves conductivity

2. Nickel-plated: prevent copper layer through the gold layer

3. Rhodium-plated: improves conductivity and prevents corrosion

．Rhodium plating to all the plug pins

．304 stainless steel screws

．Gorgeous silver baking varnish housing

．Adaptable cord clamp insert

．Provide customized shell housing dyeing services

．Accept OEM service, design service and Logo printing

Audio Grade Hi-Fi BS1363 Britain UK AC Connector Black, Gold Plated

Audio Grade Hi-Fi UK BS1363 Outlet Socket, Black, Gold Plated

BS1363 Power Socket, 1U 45mm*45mm, UK/European (Server Rack/Rackmount Power Outlet)

Jake Time Co., Ltd.

Our company was established in 1994. Specially produce. Buy and sell. All kinds of sockets. Plug. Switch. Especially to NEMA series. Been strengthening all the time. Research and development. Manufacture. Obtain the authentication of UL and CUL. Accord with ROSH standard..

Product Categories

Quick Links

Product Item :	JT-BP-8SL-77
Global Standard :	UK BS1363 (British Standard)
Poles :	2 Pole
Wires :	3 Wire Grounding
Rated Standard :	AC 250V/13A
Dielectric Voltage :	1250V AC/1 minute
Insulation Resistance :	100MΩ at 500V DC
Fire Rating :	UL 94V-0~2
Safety Certification :	UKCA approved
Environmental Certification :	RoHS approved
Terminal Material (optional) :	Brass or Copper
Plating (optional) :	Gold, Rhodium and Silver
Manufacture :	Made in Taiwan
Delivery Way - Date Of Delivery :	Depend on your order
Maximum Diameter Of Cable :	20mm
Sales Method :	Export, Manufacture
Packaging Method :	200pcs Per Packing
Payment Terms :	T/T

Product Item :	JT-BP-8SL-77
Global Standard :	UK BS1363 (British Standard)
Poles :	2 Pole
Wires :	3 Wire Grounding
Rated Standard :	AC 250V/13A
Dielectric Voltage :	1250V AC/1 minute
Insulation Resistance :	100MΩ at 500V DC
Fire Rating :	UL 94V-0~2
Safety Certification :	UKCA approved
Environmental Certification :	RoHS approved
Terminal Material (optional) :	Brass or Copper
Plating (optional) :	Gold, Rhodium and Silver
Manufacture :	Made in Taiwan
Delivery Way - Date Of Delivery :	Depend on your order
Maximum Diameter Of Cable :	20mm
Sales Method :	Export, Manufacture
Packaging Method :	200pcs Per Packing
Payment Terms :	T/T
