24K Gold-plated Audio Grade AC Power Australia Plug

Specifications
• Product NO : JT-AP
• Voltage: AC 250V /15A
• Body material : PC 94V-2~0
• All Screw material : stainless steel 304.
• Terminal Material : Brass
• Plating : All Screw .Brassr plating 24k Gold
• carbon fiber gold Colour shell receptacle
• Maximum Diameter of cable: 20mm
• Get certified SAA
Quantity:
  • JT-AP-51GYB2B-2200
  • JAKE TIME or OEM

Audio Grade Power Plugs & Connectors Series

組 JT-51B-2200 PC碳纖 金色 - 複製 - 複製

《product features》

.Three-layered plating process technology on terminal clamp, rivets, screws and grounding terminal
           1. Plating: improves conductivity
           2. Nickel-plated: prevent copper layer through the gold layer
           3. 24K gold-plated: improves conductivity and prevents corrosion

.3.0µm 24K gold plating to all the plug pins
.Gorgeous Golden baking varnish carbon fiber housing
.304 stainless steel hardware
.carbon fiber rear housing
.Adaptable cord clamp insert
.Voltage/voltage: 10A, 15A/230V
.Provide customized housing dying services
.Accept OEM service, design service and Logo printing



Audio Grade Power Plugs & Connectors Series

組 JT-51B-2200 PC碳纖 金色 - 複製 - 複製

《product features》

.Three-layered plating process technology on terminal clamp, rivets, screws and grounding terminal
           1. Plating: improves conductivity
           2. Nickel-plated: prevent copper layer through the gold layer
           3. 24K gold-plated: improves conductivity and prevents corrosion

.3.0µm 24K gold plating to all the plug pins
.Gorgeous Golden baking varnish carbon fiber housing
.304 stainless steel hardware
.carbon fiber rear housing
.Adaptable cord clamp insert
.Voltage/voltage: 16A/250V
.Provide customized housing dying services
.Logo printing is acceptable



《Product Description》

Product Item : JT-AP-51BG2B-2200
Standard: AS/NZS 3112 (Australia Plug is mainly used in Australia, New Zealand, Papua New Guinea, China and Argentina. )
Rated Current: 10Amp, 15Amp
Rated Voltage: 230V, AC
Dielectric Voltage : 1250V AC
Insulation Resistance : 1000MΩ at 500V DC/1 minute
Flammability: 94V-0~1
Environmental Certification: RoHS approved
Terminal Material (optional): brass, pure copper, gold, silver, nickel
Manufacture: Made in Taiwan
